คุณสมบัติ | รายละเอียด |
|---|---|
| Number of Contacts | 8 |
| Mounting Type | Cable Mount |
| Connector Size | Standard |
| Plug/Socket | Socket |
| Contact Gender | Female |
| Termination Method | Crimp |
| IP Rating | IP68, IP69K |
| Current Rating | 10.0A |
| Series | UTS |
| Body Orientation | Straight |
| Mating Type | Bayonet |
| Shell Size | 12 |
| Housing Material | Thermoplastic |
| Strain Relief | No |
| Contact Plating | Gold |
| Maximum Operating Temperature | +105°C |
| Minimum Operating Temperature | -40°C |
| Contact Material | Copper |
99-5101-15-02
PHG.1B.302.CLLD52
M12A-08PFFR-EE0001
8P-03BMMM-SR7B01
8STA01435SN
21033491501
