คุณสมบัติ | รายละเอียด |
|---|---|
| Terminated/Unterminated | Unterminated |
| Coaxial Type | RG214/U |
| Outer Diameter | 10.8mm |
| Characteristic Impedance | 50 Ω |
| Attenuation | 26.6 dB/100 m @ 1 GHz |
| Length | 25m |
| Sheath Colour | Black |
| Conductor Strand Type | Stranded |
| Fire Behaviour | Flame Retardant, Self-extinguishing |
| Number of Strands | 7 |
| Core Strands | 7/0.75 |
| Operating Temperature Range | -10 - +70 °C |
| Sheath Material | Polyvinyl Chloride PVC |
| Shielding | Double Braid - Silver Plated Copper |
| Insulation Material | PE |
| Velocity ratio | 66% |
| Minimum Operating Temperature | -10°C |
| Capacitance | 100pF/m |
| Conductor Material | Silver Plated Copper |
| Size of Strands | 0.75 mm |
| Maximum Operating Temperature | +70°C |
| Standards Met | IEC 60332-1 |
