คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 15V dc |
| Input Voltage Range | 40 → 160 V dc |
| Power Rating | 10W |
| Input Voltage Nominal | 110 V dc |
| Output Current | 670mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | DIP |
| Isolation Voltage | 3kV dc |
| Width | 25.4mm |
| Depth | 11mm |
| Length | 50.8mm |
| Series | ERM |
| Railway Approved | Yes |
| Load Regulation | ±0.5% |
| Maximum Temperature | +85°C |
| Standards Met | EN45545-2, EN50121-3-2, IEC/EN 50155 (IEC60571), IEC/EN 62368-1 (60950-1), UL/cUL 62368-1 (60950-1) |
| Minimum Temperature | -40°C |
| Efficiency | 85% |
