คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 16.8 → 150 V dc |
| Power Rating | 240W |
| Input Voltage Nominal | 110 V dc |
| Output Current | 10A |
| Mounting Type | Rack Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Isolation Voltage | 2 kV ac, 2.8kV dc |
| Length | 60mm |
| Depth | 171.9mm |
| Railway Approved | Yes |
| Series | HR |
| Load Regulation | ±120mV |
| Maximum Temperature | +71°C |
| Standards Met | CSA 62368-1, EN 45545, EN 50121-3-2:2016, EN 50155, EN 62368-1, IEC 62368-1, UL 62368-1 |
| Efficiency | 94% |
| Medical Approved | No |
| Minimum Temperature | -40°C |
THL 15-4823WI
