คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 1 A |
| Mounting Type | Surface Mount |
| Maximum Load Voltage | 60 V |
| Minimum Load Voltage | -60 V |
| Maximum Control Voltage | 0.8 V |
| Minimum Control Voltage | 0 V |
| Switching Type | AC/DC |
| Control Voltage Range | 0 → 0.8 V |
| Number of Poles | 1 |
| Contact Configuration | SPST |
| Terminal Type | 8 Pin |
| Output Device | MOSFET |
| Package Style | SOIC |
| Relay Type | PhotoMOSFET |
| Maximum Turn On Time | 2ms |
| Series | ASSR-15XX |
| Load Voltage Range | -60 → +60V |
| Dimensions | 9.4 x 4.4 x 2mm |
| Maximum Operating Temperature | +85°C |
| Depth | 4.4mm |
| Capacitance | 0.5pF |
| Height | 2mm |
| Minimum Operating Temperature | -40°C |
| Off State Leakage Current | 1 μA |
| Length | 9.4mm |
| Operating Temperature Range | -40 → +85°C |
| Special Features | Compact Solid-State Bi-directional Signal Switch |
| Standards Met | RoHS Compliant |
