คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 110 V ac |
| Number of Poles | 3 |
| Contact Voltage Rating | 400 V ac |
| Contact Current Rating | 9 A |
| Power Rating | 4 kW |
| Range | xStart |
| Function | Reversing |
| Normal State Configuration | 3NO |
| Auxiliary Contact Configuration | 1NO |
| Number Of Auxiliary Contacts | 1 |
| Terminal Type | Screw |
| Width | 45mm |
| Length | 68mm |
| Depth | 117mm |
| Mounting Style | Tabletop |
| Minimum Operating Temperature | -25°C |
| Pole and Throw Configuration | 3P |
| Maximum Operating Temperature | +40°C |
| Control Voltage | 110 V |
3RH2122-1AP00
LC1D0986FDS207
3RT2035-1AV00
3RT2015-1BB42-0CC0
3RT2025-1AF00
1SBL156082R3022 AFS12Z-30-22-30
