คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24 V dc |
| Number of Poles | 3 |
| Contact Voltage Rating | 400 V ac |
| Contact Current Rating | 15 A |
| Power Rating | 7.5 kW |
| Range | xStart |
| Normal State Configuration | 3NO |
| Auxiliary Contact Configuration | 1NO |
| Number Of Auxiliary Contacts | 1 |
| Terminal Type | Screw |
| Length | 68mm |
| Width | 45mm |
| Depth | 75mm |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +50°C |
| Pole and Throw Configuration | 3P |
| Mounting Style | DIN Rail |
276865 DILM12-01(230V50HZ,240V60HZ)
GJL1213001R7011 - B6S-30-01-1.7-71
3RT2025-1FB40
GJL1311911R8015 VB7A-30-01 380-415V AC
051777 DILER-22(230V50HZ,240V60HZ)
3RH2122-1JB40
