คุณสมบัติ | รายละเอียด |
|---|---|
| Port Connection | G 1/4 |
| Maximum Operating Pressure | 14 bar |
| Manufacturer Series | MS |
| Drain Type | Manual |
| Filtration Size | 40µm |
| Pressure Gauge Port | G 1/4 |
| Pressure Gauge Port Thread Size | 1/4 in |
| Port Connection Thread Size | 1/4 in |
| Maximum Ambient Operating Temperature | +60°C |
| Minimum Process Operating Temperature | -10°C |
| Minimum Operating Pressure | 0.8bar |
| Proof Pressure | 12bar |
| Ambient Operating Temperature Range | -10 - +60°C |
| Minimum Ambient Operating Temperature | -10°C |
| Maximum Process Operating Temperature | +60°C |
| Pressure Gauge Port Thread Standard | G |
| Bowl Material | Plastic |
| Port Connection Thread Standard | G |
| Process Operating Temperature Range | -10 - +60°C |
P31QN12MEMNTW
MS4-LFR-1/8-D6-ERV-AS
LFR-1/2-D-MIDI-A
AW30-F03DG-B
AW30-F02DE-B
LFR-1/2-D-5M-MIDI
MS4-LFR-1/4-D7-CRV-AS-Z
