คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 110V ac |
| Contact Configuration | SPDT |
| Mounting Type | Plug In |
| Switching Current | 25A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | Quick Connect |
| Maximum Switching Voltage AC | 250V ac |
| Length | 29mm |
| Coil Resistance | 6.9 kΩ |
| Coil Power | 1.2W |
| Height | 32.8mm |
| Depth | 12.4mm |
| Maximum Operating Temperature | +70°C |
| Contact Material | Silver Alloy |
| Minimum Operating Temperature | -40°C |
| Series | 46 Series |
| Isolation Coil To Contact | 6kV |
| Maximum Switching Power AC | 4 kVA |
| Application | General Purpose |
