คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | SPST |
| Mounting Type | PCB Mount |
| Switching Current | 12 A, 16A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | PCB Pin |
| Maximum Switching Voltage AC | 400V |
| Maximum Switching Current AC | 12 A, 16 A |
| Length | 29mm |
| Coil Resistance | 1440Ω |
| Coil Power | 400mW |
| Contact Material | Silver Alloy |
| Depth | 12.7mm |
| Life | 1 x 10^7 cycles |
| Maximum Operating Temperature | +85°C |
| Isolation Coil To Contact | 10kV |
| Height | 15.7mm |
| Series | HF115FK |
| Minimum Operating Temperature | -40°C |
| Maximum Switching Power AC | 3 kVA, 4 kVA |
