คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current AC | 2 A |
| Maximum Switching Current DC | 2 A |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Series | EC2 |
| Maximum Switching Power DC | 60 W |
| Length | 15mm |
| Latching | Yes |
| Depth | 7.5mm |
| Height | 9.4mm |
| Dimensions | 15 x 7.5 x 9.4mm |
| Terminal Type | Through Hole |
| Number of Poles | 2 |
| Switching Current | 2A |
| Application | Electronic Switching Systems, PBX, Telecommunications, Terminal Equipment |
| Maximum Switching Power AC | 125VA |
| Coil Power | 140mW |
| Coil Resistance | 1028Ω |
| Maximum Operating Temperature | +85°C |
| Isolation Coil To Contact | 1kV ac |
| Relay Switching Classification | Latching Relay |
| Standards Met | CSA, UL Recognized E73266 |
| Contact Material | Gold Plated |
| Operating Temperature Range | -40 → +85°C |
| Features | Compact and Lightweight, Low Magnetic Interference, Low Power Consumption |
| Minimum Operating Temperature | -40°C |
