คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 15V dc |
| Input Voltage Range | 10.8 → 13.2 V dc |
| Power Rating | 2W |
| Input Voltage Nominal | 12 V dc |
| Output Current | 133mA |
| Mounting Type | Surface Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | iLGA |
| Isolation Voltage | 3kV dc |
| Length | 12.7mm |
| Depth | 4.41mm |
| Width | 10.41mm |
| Series | NXE2 |
| Load Regulation | Maximum of 11% |
| Maximum Temperature | +85°C |
| Efficiency | 79% |
| Minimum Temperature | -40°C |
