คุณสมบัติ | รายละเอียด |
|---|---|
| Series | A-Coded |
| Number of Cores | 5 |
| Cross Sectional Area | 0.34 mm² |
| Length | 3m |
| Sheath Colour | Blue |
| Sheath Material | TPE |
| Connector 1 | M12 |
| Connector 1 Orientation | Right Angle |
| Connector 1 Number of Contacts | 5 |
| Connector 1 Gender | Female |
| Connector 2 | Unterminated |
| Current Rating | 4 A |
| Voltage Rating | 24 V |
| IP Rating | IP65, IP68, IP69K |
| Operating Temperature Range | -25 → +105 (Mobile) °C, -25 → +105 °C, -40 → +105 (Fixed) °C |
| Cable Shape | Single Core |
| Oil Resistant | Yes |
| Maximum Operating Temperature | +105 (Fixed, +105 °C, Mobile) °C |
| Minimum Operating Temperature | -25 (Mobile) °C, -40 (Fixed) °C |
| Size of Strands | 0.1 mm |
| Fire Behaviour | Halogen Free |
| Insulation Material | PP |
| Minimum Bend Radius | 25 (Fixed) mm, 50 (Moving) mm |
| Conductor Resistance | 58 O/km |
| American Wire Gauge | 22 AWG |
| Core Strands | 42 x 0.1 mm |
| Outer Diameter | 5mm |
| Number of Strands | 42 |
| Connector 1 Housing Gender | Female |
T41511C9L25-003
21348300481100
M12A-05BFFM-SL8N05
51487 RKT 5-289/2 M
