คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 60 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 264 V |
| Minimum Load Voltage | 19 V ac |
| Maximum Control Voltage | 30 V |
| Switching Type | Zero Crossing |
| Control Voltage Range | 4 - 30 V dc |
| Minimum Load Current | 0.5 A |
| Output Device | Triac |
| Series | G3PA |
| Load Voltage Range | 19 - 264V ac |
| Dimensions | 100 x 110 x 100mm |
| Length | 100mm |
| Depth | 110mm |
| Maximum Operating Temperature | +80°C |
| Operating Temperature Range | -30 - +80°C |
| Minimum Operating Temperature | -30°C |
| Height | 100mm |
