คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current DC | 2 A |
| Maximum Switching Voltage AC | 125V |
| Maximum Switching Voltage DC | 125V |
| Series | MT |
| Maximum Switching Power DC | 60 W |
| Length | 20.2mm |
| Latching | No |
| Depth | 10mm |
| Height | 11.5mm |
| Dimensions | 20.5 x 10 x 11.5mm |
| Terminal Type | Through Hole |
| Application | Signal |
| Switching Current | 2A |
| Number of Poles | 2 |
| Coil Power | 500mW |
| Coil Resistance | 1.152 kΩ |
| Features | Conforms to FCC Part 68 Requirements, Bifurcated Contacts |
| Relay Switching Classification | Miniature Relay |
| Maximum Operating Temperature | +70°C |
| Contact Material | Gold Plated |
| Minimum Operating Temperature | -25°C |
| Maximum Switching Power AC | 62.5 VA |
| Operating Temperature Range | -25 → +70°C |
| Electrical Life | 10^5 Operations |
