คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | DPDT |
| Mounting Type | Surface Mount |
| Maximum Switching Current DC | 2 A |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Maximum Switching Power DC | 60 W |
| Series | HFD27 |
| Length | 14.8mm |
| Latching | No |
| Depth | 7.3mm |
| Height | 9.2mm |
| Dimensions | 14.8 x 9.2 x 7.3mm |
| Terminal Type | Surface Mount |
| Number of Poles | 2 |
| Switching Current | 2A |
| Minimum Operating Temperature | -40°C |
| Electrical Life | 100000 Operations |
| Contact Material | Silver Alloy |
| Features | Space Saving Inside L Terminal, Low Power Consumption, Applicable To IRS, High Saleability After IRS |
| Operating Temperature Range | -40 → +85°C |
| Maximum Switching Power AC | 62.5VA |
| Isolation Coil To Contact | 1.5kV ac |
| Maximum Operating Temperature | +85°C |
| Coil Power | 140mW |
| Coil Resistance | 178Ω |
V23101D 107A201
G6AU-274P-ST-US 5DC
G6S-2-Y DC9
V23101D7B201
V23079-D2003-B301
1-1393763-6
