คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | DPDT |
| Mounting Type | Surface Mount |
| Maximum Switching Current AC | 0.3 A |
| Maximum Switching Current DC | 1 A |
| Maximum Switching Voltage AC | 125V |
| Maximum Switching Voltage DC | 110V |
| Maximum Switching Power DC | 30 W |
| Series | FTR-B4 |
| Latching | No |
| Length | 10.9mm |
| Depth | 7.2mm |
| Height | 5.2mm |
| Dimensions | 10 x 5.2 x 7.2mm |
| Terminal Type | PCB Pin |
| Number of Poles | 2 |
| Switching Current | 1A |
| Electrical Life | 100000 Operations Cycles |
| Isolation Coil To Contact | 2.5kV |
| Features | Compact Slim Body Saves Space, Increased Packaging Density, Sealed Construction allows Automatic Washing. |
| Operating Temperature Range | -40 → +85°C |
| Coil Resistance | 1.028 kΩ |
| Maximum Switching Power AC | 37.5 VA |
| Life | 100000 (Electrical) cycles, 50000000 (Mechanical) cycles |
| Coil Power | 140mW |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Contact Material | Au Plated AgPd |
