คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Switching Current | 3A |
| Number of Poles | 2 |
| Latching | No |
| Terminal Type | PCB Pin |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 48V dc |
| Length | 28mm |
| Coil Resistance | 720Ω |
| Coil Power | 200mW |
| Minimum Operating Temperature | -55°C |
| Life | 10 ^8 (Mechanical) Operations, 10^5 (Electrical-AC) Operations, 2 x 10^5 (Electrical-DC) Operations |
| Height | 10.5mm |
| Maximum Operating Temperature | +65°C |
| Isolation Coil To Contact | 1.5kVrms |
| Depth | 12mm |
| Maximum Switching Power DC | 90 W |
| Maximum Switching Power AC | 1 kVA |
| Application | Office Equipment, Safety, Telecommunications |
