คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current DC | 2 A |
| Maximum Switching Voltage DC | 220V |
| Maximum Switching Power DC | 60 W |
| Series | SY |
| Length | 15mm |
| Latching | No |
| Depth | 7.4mm |
| Height | 8.2mm |
| Dimensions | 15 x 8.2 x 7.4mm |
| Terminal Type | PCB Pin |
| Switching Current | 2A |
| Application | Domestic Appliances, General Purpose, Medical Equipment, Safety |
| Number of Poles | 2 |
| Isolation Coil To Contact | 1.5kV rms |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Contact Material | Gold Plated |
| Features | Outstanding Surge Resistance, Sealed Construction Allows Automatic Washing, |
| Operating Temperature Range | -40 → +85°C |
| Coil Resistance | 1020Ω |
| Life | 1 x 10^5 (Electrical) Operations, 10^8 (Mechanical) Operations |
| Coil Power | 140mW |
