คุณสมบัติ | รายละเอียด |
|---|---|
| Series | SAC-12P |
| Number of Cores | 12 |
| Cross Sectional Area | 0.14 mm² |
| Sheath Material | PUR |
| Sheath Colour | Black |
| Length | 5m |
| Connector 1 Gender | Female |
| Connector 1 Orientation | Straight |
| Connector 1 Number of Contacts | 12 |
| Connector 1 | M12 |
| Connector 2 | Unterminated |
| Connector 2 Orientation | Straight |
| Connector 2 Number of Contacts | 12 |
| Coding | A |
| Shielded/Unshielded | Unshielded |
| Armoured | No |
| Voltage Rating | 30 V ac |
| Current Rating | 1.5 A |
| IP Rating | IP65, IP67, IP68 |
| Insulation Material | PP |
| Conductor Resistance | 142 O/km |
| Outer Diameter | 7.2mm |
| Cable Shape | Twisted |
| Operating Temperature Range | -40 - +80 °C |
| Maximum Operating Temperature | +80°C |
| Number of Strands | 1 |
| Oil Resistant | Yes |
| Fire Behaviour | Halogen Free |
| Minimum Operating Temperature | -40°C |
| Standards Met | EAC |
| Conductor Material | Tin Plated Copper Litz Wires |
| Minimum Bend Radius | 12 mm |
