คุณสมบัติ | รายละเอียด |
|---|---|
| Series | SAC |
| Number of Cores | 5 |
| Sheath Colour | Black |
| Sheath Material | PUR |
| Length | 1.5m |
| Connector 1 | M12 |
| Connector 1 Orientation | Straight |
| Connector 1 Gender | Male |
| Connector 1 Number of Contacts | 5 |
| Connector 2 Gender | Female |
| Connector 2 | M12 |
| Connector 2 Number of Contacts | 5 |
| Connector 2 Orientation | Straight |
| Connector 2 Housing Gender | Female |
| Coding | A |
| Shielded/Unshielded | Shielded |
| Current Rating | 4 A |
| Voltage Rating | 60 V |
| IP Rating | IP65, IP67 |
| Operating Temperature Range | -40 - +80 °C |
| Maximum Operating Temperature | +80°C |
| Connector 1 Housing Gender | Male |
| Minimum Operating Temperature | -40°C |
| Insulation Material | PP |
| Conductor Resistance | 57 Ω/km |
| Oil Resistant | Yes |
| Standards Met | EAC |
| Conductor Material | Bare Cu litz wires |
| Minimum Bend Radius | 59 mm (Flexible) 29 mm (Fixed) |
| American Wire Gauge | 22 AWG |
