คุณสมบัติ | รายละเอียด |
|---|---|
| Series | SAC |
| Cross Sectional Area | 0.25 mm² |
| Number of Cores | 8 |
| Sheath Colour | Black |
| Sheath Material | PUR |
| Length | 1.5m |
| Connector 1 | M12 |
| Connector 1 Gender | Male |
| Connector 1 Number of Contacts | 8 |
| Connector 2 Number of Contacts | 8 |
| Connector 2 Gender | Female |
| Connector 2 Housing Gender | Female |
| Connector 2 | M12 |
| Coding | A |
| Shielding | Tinned Copper Braid |
| Shielded/Unshielded | Shielded |
| Voltage Rating | 30 V |
| Current Rating | 2 A |
| IP Rating | IP65, IP67 |
| Minimum Operating Temperature | -5 (Flexible) °C, -25 (Fixed) °C |
| Insulation Material | PP |
| Fire Behaviour | Halogen Free |
| Standards Met | cUL, cULus, EAC, IEC 61076-2-104, UL |
| Outer Diameter | 5.9mm |
| Minimum Bend Radius | 59 mm (Flexible) 47 mm (Fixed) |
| American Wire Gauge | 24 AWG |
| Maximum Operating Temperature | +80°C |
| Conductor Material | Bare Cu litz wires |
| Connector 1 Housing Gender | Male |
| Conductor Resistance | 78 O/km |
| Oil Resistant | Yes |
