คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 230V ac |
| Railway Approved | Yes |
| Efficiency | 0.86 |
| MTBF | 160000h |
| Output Current | 3.26A |
| Length | 270.5mm |
| Width | 52.5mm |
| Depth | 160mm |
| Weight | 2kg |
| Minimum Temperature | -25°C |
| Special Features | High Input-Output Isolation 3000 Vrms, Input & Output Alarm, Remote Inhibit, Selectable Output Frequency 50/60 Hz, Sine Wave Output Voltage, Three-Phase Synchronisation |
| Standards Met | 2014/30/EU, 2014/35/EU, EN 45545-2, EN 50121-3-2, EN 50121-4, EN 50155, EN 62368-1 |
| Maximum Temperature | +55°C |
| Protection Features | Current Protection, Overload Protection, Polarity Protection, Power Protection |
| Mounting Type | Chassis Mount |
| Maximum Input Current | 460mA |
A302-150-F3
