คุณสมบัติ | รายละเอียด |
|---|---|
| Number of Cores | 4 |
| Cross Sectional Area | 0.25 mm² |
| Sheath Colour | Grey |
| Sheath Material | PUR |
| Length | 2m |
| Connector 1 Number of Contacts | 4 |
| Connector 1 | M12 |
| Connector 1 Orientation | Right Angle |
| Connector 1 Gender | Female |
| Connector 2 Orientation | Straight |
| Connector 2 Housing Gender | Male |
| Connector 2 Gender | Male |
| Connector 2 Number of Contacts | 4 |
| Connector 2 | M12 |
| Shielded/Unshielded | Unshielded |
| Voltage Rating | 24 V dc |
| Current Rating | 4 A |
| IP Rating | IP65, IP66K, IP67, IP68 |
| Fire Behaviour | Flame Retardant |
| Minimum Operating Temperature | -25°C |
| Insulation Material | PVC |
| Conductor Resistance | 60 Ω/km |
| Outer Diameter | 5mm |
| Connector 1 Housing Gender | Female |
| Number of Strands | 19 |
| Operating Temperature Range | -25 → +85 °C |
| American Wire Gauge | 24 AWG |
| Maximum Operating Temperature | +85°C |
| Core Strands | 19/0.15 mm |
| Minimum Bend Radius | 10 x 5 mm, 5 x 5 mm |
| Conductor Material | Copper |
| Size of Strands | 0.15 mm |
| Oil Resistant | Yes |
| Standards Met | CSA, EN 60529, UL |
| Cable Shape | Multicore |
