คุณสมบัติ | รายละเอียด |
|---|---|
| Terminated/Unterminated | Unterminated |
| Coaxial Type | Solid |
| Outer Diameter | 5.4mm |
| Characteristic Impedance | 50 Ω |
| Attenuation | 28.6 dB/100 m@ 400 MhZ |
| Length | 100m |
| Sheath Colour | Black |
| Fire Behaviour | Flame Retardant, Self-extinguishing |
| Conductor Strand Type | Solid |
| Operating Temperature Range | -30 °C-+70 °C |
| Core Strands | 1 |
| Shielding | Double Braid - Silver Plated Copper |
| Insulation Material | PE |
| Sheath Material | PVC |
| Capacitance | 100pF/m |
| Number of Strands | 1 |
| Size of Strands | 0.90 mm |
| Maximum Operating Temperature | +70°C |
| Minimum Operating Temperature | -10°C |
| Conductor Material | Silver Plated Copper |
| Velocity ratio | 0.66 |
415-0054-024
30-07837-10/A
