คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Switching Current | 5A |
| Number of Poles | 2 |
| Latching | No |
| Terminal Type | Through Hole |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 30V dc |
| Length | 28.8mm |
| Coil Resistance | 224 Ω |
| Coil Power | 700mW |
| Life | 10 Million (AC Mechanical) cycles, 20 Million (DC Mechanical) cycles |
| Height | 35.4mm |
| Contact Material | Gold Plated |
| Depth | 12.5mm |
| Series | C12 |
| Minimum Operating Temperature | -40°C |
| Isolation Coil To Contact | 5kV |
| Maximum Operating Temperature | +60°C |
| Maximum Switching Power AC | 1.2 kVA |
| Application | General Purpose |
