คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 90 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 660 V rms |
| Minimum Load Voltage | 48 V rms |
| Maximum Control Voltage | 32 V dc |
| Minimum Control Voltage | 4 V dc |
| Switching Type | Instantaneous |
| Control Voltage Range | 4 - 32 V dc |
| Minimum Load Current | 150 mA rms |
| Terminal Type | Screw |
| Output Device | SCR |
| Relay Type | Solid State Relay |
| Maximum Turn On Time | 1/2 ms |
| Series | H12WD |
| Load Voltage Range | 48 - 660Vrms |
| Dimensions | 45.7 x 19.8 x 58.4mm |
| Capacitance | 8pF |
| Depth | 19.8mm |
| Maximum Operating Temperature | +80°C |
| Off State Leakage Current | 1 mA rms |
| Special Features | SCR Output For Heavy Industrial Loads, Redesigned Housing With Anti Rotation Barriers |
| Operating Temperature Range | -40 - +80°C |
| Length | 45.7mm |
| Minimum Operating Temperature | -40°C |
| Height | 58.4mm |
