คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 25 A rms |
| Mounting Type | DIN Rail |
| Maximum Load Voltage | 280 V rms |
| Minimum Load Voltage | 24 V rms |
| Maximum Control Voltage | 32 V dc |
| Minimum Control Voltage | 3 V dc |
| Switching Type | Zero Cross |
| Control Voltage Range | 3 → 32 V dc |
| Minimum Load Current | 0.1 A rms |
| Terminal Type | Screw |
| Load Voltage Range | 24 → 280Vrms |
| Maximum Turn On Time | 1/2 cycle |
| Dimensions | 45 x 81 x 79.2mm |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -20°C |
| Operating Temperature Range | -20 → +80°C |
| Length | 45mm |
| Height | 79.2mm |
| Depth | 81mm |
| Off State Leakage Current | 0.1 mA rms |
RGC1A60D32KKE
