คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 50 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 280 V rms |
| Minimum Load Voltage | 180 V rms |
| Minimum Control Voltage | 8 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | DC |
| Control Voltage Range | 8 → 32 V dc |
| Minimum Load Current | 150 mA |
| Range | Crydom |
| Terminal Type | Screw |
| Relay Type | Control Relay |
| Series | MCPC |
| Load Voltage Range | 180 → 280Vrms |
| Dimensions | 45.7 x 58.4 x 19.8mm |
| Minimum Operating Temperature | -20°C |
| Standards Met | CE, RoHS Compliant |
| Special Features | Input Type 4-20mA |
| Operating Temperature Range | -20 → +80°C |
| Length | 45.7mm |
| Off State Leakage Current | 7 mArms |
| Height | 19.8mm |
| Capacitance | 10pF |
| Depth | 58.4mm |
| Maximum Operating Temperature | +80°C |
SSP1D412BDT
