คุณสมบัติ | รายละเอียด |
|---|---|
| Series | DSL |
| Cross Sectional Area | 0.25 mm² |
| Number of Cores | 7 |
| Sheath Colour | Black |
| Length | 20m |
| Sheath Material | Polyurethane PUR |
| Connector 1 Gender | Female |
| Connector 1 Number of Contacts | 8 |
| Connector 1 | M12 |
| Connector 1 Orientation | Straight |
| Connector 2 | M12 |
| Connector 2 Orientation | Straight |
| Connector 2 Number of Contacts | 8 |
| Connector 2 Gender | Male |
| Connector 2 Housing Gender | Male |
| Mounting Type | Plug-In |
| Shielding | Shielded |
| Shielded/Unshielded | Shielded |
| Voltage Rating | 30 V |
| Current Rating | 2 A |
| IP Rating | IP65, IP67 |
| Standards Met | UL |
| Minimum Operating Temperature | -25°C |
| Cable Shape | Round |
| Outer Diameter | 6mm |
| Connector 1 Housing Gender | Female |
| American Wire Gauge | 24 |
| Minimum Bend Radius | 60 mm |
| Operating Temperature Range | -25 → 80 °C |
| Maximum Operating Temperature | +80°C |
