คุณสมบัติ | รายละเอียด |
---|---|
Thread Size | M12 |
Sensor Technology | Inductive |
Detection Range | 2 mm |
Body Style | Barrel |
Digital Switching Output Type | NPN |
Output Function | NO |
Connection Type | Pre-Cabled |
Cable Length | 2m |
Supply Voltage | 10 → 30 V dc |
IP Rating | IP67 |
Length | 44mm |
Mounting Type | Flush |
Housing Material | Metal |
Width | 12mm |
Maximum DC Voltage | 30V |
Minimum Operating Temperature | -30°C |
Reverse Polarity Protection | Yes |
Maximum Switching Frequency | 2kHz |
Short Circuit Overload Protection | Yes |
Switching Current | 200 mA |
Shielding | Shielded |
Maximum Operating Temperature | +75°C |
Switching Frequency | 2 kHz |
Series | IME |
