คุณสมบัติ | รายละเอียด |
---|---|
Thread Size | M12 |
Sensor Technology | Inductive |
Detection Range | 10 mm |
Body Style | Barrel |
Digital Switching Output Type | PNP |
Output Function | NO |
Connection Type | M12 |
Supply Voltage | 10 → 30 V dc |
IP Rating | IP67 |
Length | 44mm |
Mounting Type | Non-Flush |
Housing Material | Brass Nickel Plated |
Width | 12mm |
Maximum DC Voltage | 30V |
Minimum Operating Temperature | -25°C |
Maximum Switching Frequency | 400Hz |
Shielding | Unshielded |
Reverse Polarity Protection | Yes |
Switching Current | 200 mA |
Standards Met | CE Certified UKCA |
Switching Frequency | 400 Hz |
Short Circuit Overload Protection | Yes |
Maximum Operating Temperature | +75°C |
Series | IME |
