คุณสมบัติ | รายละเอียด |
|---|---|
| Series | YM2X18 |
| Number of Cores | 8 |
| Cross Sectional Area | 0.14 mm² |
| Sheath Material | Polyurethane PUR |
| Length | 5m |
| Sheath Colour | Black |
| Connector 1 Number of Contacts | 8 |
| Connector 1 Orientation | Straight |
| Connector 1 Gender | Male |
| Connector 1 | M12 |
| Connector 2 | RJ45 |
| Connector 2 Housing Gender | Male |
| Connector 2 Gender | Male |
| Connector 2 Orientation | Straight |
| Connector 2 Number of Contacts | 8 |
| Coding | X |
| Shielding | Shielded |
| Shielded/Unshielded | Shielded |
| Voltage Rating | 48/60 V ac/dc |
| Current Rating | 500 mA |
| IP Rating | IP65, IP67 |
| Minimum Bend Radius | 64 mm |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +80°C |
| Operating Temperature Range | -40 → 80 °C |
| Standards Met | CE |
| Outer Diameter | 6.4mm |
| Connector 1 Housing Gender | Male |
| American Wire Gauge | 26 AWG |
