คุณสมบัติ | รายละเอียด |
|---|---|
| Module Type | Isolation Amplifier |
| Input Signal Type | Current, Voltage |
| Output Signal Type | Current, Voltage |
| Input Range | 0 - 1 V, 0 - 10 mA, 0 - 100 mV, 0 - 2 V, 0 - 20 mA, 0 - 20 V, 0 - 300 mV, 0 - 5 V, 0 - 5 mA, 0 - 500 mV, 0 - 60 mV, 0 to10 V, 2 to10 V, -20 - +20 mA, 4 - 20 mA, -5 - +5mA |
| Output Range | 0 - 10 V, 0 - 20 mA, 4 - 20mA |
| Supply Voltage | 24V ac/dc |
| Mounting Type | DIN Rail Mount |
| Operating Temperature Range | -25 - +60°C |
| Series | 3RS7006 |
| Minimum Operating Temperature | -25°C |
| Termination | Spring-Loaded |
| Maximum Operating Temperature | +60°C |
