คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24 V dc |
| Number of Poles | 3 |
| Contact Voltage Rating | 400 V ac |
| Contact Current Rating | 9 A |
| Series | 3RT2 |
| Range | SIRIUS |
| Power Rating | 4 kW |
| Normal State Configuration | 3NO |
| Auxiliary Contact Configuration | 2NO + 2NC |
| Number Of Auxiliary Contacts | 4 |
| Terminal Type | Screw |
| Length | 45mm |
| Width | 45mm |
| Depth | 117mm |
| Better World Product | Yes |
| Better World Claim | Low carbon manufacture |
| Minimum Operating Temperature | -25°C |
| Pole and Throw Configuration | 3PST |
| Maximum Operating Temperature | +60°C |
