คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 230 V ac |
| Number of Poles | 3 |
| Contact Voltage Rating | 400 V ac |
| Contact Current Rating | 38 A |
| Series | 3RT2 |
| Range | SIRIUS |
| Power Rating | 18.5 kW |
| Normal State Configuration | 3NO |
| Number Of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1NO + 1NC |
| Terminal Type | Screw |
| Length | 45mm |
| Width | 85mm |
| Depth | 97mm |
| Better World Claim | Low carbon manufacture |
| Better World Product | Yes |
| Minimum Operating Temperature | -25°C |
| Pole and Throw Configuration | 3PST |
| Maximum Operating Temperature | +60°C |
