คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 18 → 36 V dc |
| Power Rating | 6W |
| Input Voltage Nominal | 24 V dc |
| Output Current | 500mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | DIP 24 |
| Isolation Voltage | 1.5kV dc |
| Width | 20.3mm |
| Length | 31.8mm |
| Depth | 10.2mm |
| Series | TEN 5 |
| Load Regulation | ±1% |
| Efficiency | 86% |
| Minimum Temperature | -40°C |
| Standards Met | IEC/UL 60950-1 |
| Maximum Temperature | +85°C |
TMR 3-2410WI
MGJ2D151515BSC
CC30-2405SFP-E
