คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 43 → 160 V dc |
| Power Rating | 8W |
| Input Voltage Nominal | 72 V dc |
| Output Current | 666mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | DIP 24 |
| Isolation Voltage | 1.5kV dc |
| Length | 32mm |
| Width | 20.3mm |
| Depth | 10.2mm |
| Railway Approved | Yes |
| Series | TEN 8WI |
| Load Regulation | ±0.5% |
| Minimum Temperature | -40°C |
| Medical Approved | No |
| Maximum Temperature | +85°C |
