คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 5V dc |
| Input Voltage Range | 18 → 36 V dc |
| Power Rating | 3W |
| Input Voltage Nominal | 24 V dc |
| Output Current | 600mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | DIP 24 |
| Isolation Voltage | 4kV dc |
| Depth | 10.5mm |
| Width | 20.3mm |
| Length | 31.8mm |
| Series | THB 3 |
| Railway Approved | No |
| Load Regulation | 1% |
| Maximum Temperature | +85°C |
| Efficiency | 78% |
| Medical Approved | Yes |
| Minimum Temperature | -40°C |
| Standards Met | CE, EN 60950-1, UL/CSA 60950-1 |
