คุณสมบัติ | รายละเอียด |
|---|---|
| Thread Size | M18 |
| Sensor Technology | Inductive |
| Detection Range | 5 mm |
| Body Style | Barrel |
| Output Function | NO |
| Digital Switching Output Type | PNP |
| Connection Type | M12 |
| Supply Voltage | 10 - 38 V dc, 12 - 24 V dc |
| IP Rating | IP67 |
| Length | 64.3mm |
| Mounting Type | Flush |
| Housing Material | Stainless Steel |
| Maximum DC Voltage | 38V |
| Minimum Operating Temperature | -25°C |
| Shielding | Shielded |
| Maximum Switching Frequency | 1kHz |
| Switching Current | 15 mA, 200 mA |
| Depth | 24mm |
| Short Circuit Overload Protection | Yes |
| Series | General Purpose |
| Standards Met | CE, CSA, UL |
| Reverse Polarity Protection | Yes |
| Maximum Operating Temperature | +70°C |
| Switching Frequency | 1 kHz |
