คุณสมบัติ | รายละเอียด |
---|---|
Thread Size | M12 |
Sensor Technology | Inductive |
Body Style | Barrel |
Detection Range | 4 mm |
Digital Switching Output Type | PNP |
Output Function | NO |
Connection Type | Pre-Cabled |
Cable Length | 5m |
Supply Voltage | 12 → 24 V dc |
Length | 44mm |
IP Rating | IP65, IP67 |
Mounting Type | Non-Flush |
Housing Material | Brass Nickel Plated |
Maximum DC Voltage | 24V |
Minimum Operating Temperature | -25°C |
Depth | 17mm |
Short Circuit Overload Protection | Yes |
Maximum Switching Frequency | 1.2kHz |
Shielding | Unshielded |
Reverse Polarity Protection | Yes |
Maximum Operating Temperature | +70°C |
Switching Frequency | 1.2 kHz |
Switching Current | 200 mA |
Series | General Purpose |
Standards Met | CE, CSA, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, UL |
BI5U-EM18H-AP6X-H1141
UC30-214163
BES M12MG-USC30B-BV03
IME08-06NPOZT0S
IM12-02BPP-ZC1
IQ40-20BPSKK0S
XS108B3PAM12
