คุณสมบัติ | รายละเอียด |
|---|---|
| Thread Size | M18 |
| Sensor Technology | Inductive |
| Body Style | Barrel |
| Detection Range | 12 mm |
| Output Function | NO |
| Digital Switching Output Type | NPN |
| Connection Type | M12 |
| Supply Voltage | 12 - 24 V dc |
| Length | 70mm |
| IP Rating | IP69K |
| Mounting Type | Non Flush |
| Housing Material | Stainless Steel |
| Maximum DC Voltage | 36V |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +85°C |
| Depth | 24mm |
| Short Circuit Overload Protection | Yes |
| Series | General Purpose |
| Switching Frequency | 1 kHz |
| Reverse Polarity Protection | Yes |
| Switching Current | 200 mA |
| Shielding | Unshielded |
| Maximum Switching Frequency | 1kHz |
