คุณสมบัติ | รายละเอียด |
|---|---|
| Thread Size | M18 |
| Sensor Technology | Inductive |
| Body Style | Barrel |
| Detection Range | 8 mm |
| Output Function | NO+NC |
| Digital Switching Output Type | PNP |
| Connection Type | Pre-Cabled |
| Cable Length | 2m |
| Supply Voltage | 10 → 36 V dc, 12 → 24 V dc |
| Length | 40.15mm |
| IP Rating | IP68 |
| Mounting Type | Non-Flush |
| Housing Material | PPS |
| Maximum DC Voltage | 36V |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +70°C |
| Reverse Polarity Protection | Yes |
| Switching Current | 200 mA |
| Short Circuit Overload Protection | Yes |
| Switching Frequency | 2 kHz |
| Standards Met | CE, CSA, UL |
| Shielding | Unshielded |
| Maximum Switching Frequency | 2kHz |
| Series | OsiSense XS |
