คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 3.3V dc |
| Input Voltage Range | 4.5 → 5.5 V dc |
| Power Rating | 2W |
| Input Voltage Nominal | 5 V dc |
| Output Current | 400mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | SIP |
| Isolation Voltage | 1kV dc |
| Width | 7.5mm |
| Depth | 10.16mm |
| Length | 11.68mm |
| Series | IL |
| Load Regulation | ±20% |
| Maximum Temperature | +85°C |
| Efficiency | 71% |
| Minimum Temperature | -40°C |
