คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 10.8 → 13.2 V dc |
| Power Rating | 1W |
| Input Voltage Nominal | 12 V dc |
| Output Current | 83.3mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | SIP |
| Isolation Voltage | 3kV dc |
| Width | 6mm |
| Length | 19.5mm |
| Depth | 10mm |
| Series | ITV |
| Load Regulation | -2.5 → +5% |
| Standards Met | EN55022, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, MIL-HDBK-217F |
| Maximum Temperature | +105°C |
| Efficiency | 80% |
| Minimum Temperature | -40°C |
