คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 24V dc |
| Input Voltage Range | 9 → 36 V dc |
| Power Rating | 400W |
| Input Voltage Nominal | 24 V dc |
| Output Current | 16.6A |
| Mounting Type | PCB Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | Full Brick |
| Isolation Voltage | 1.5kV dc |
| Depth | 5.5mm |
| Width | 57.1mm |
| Length | 116.8mm |
| Series | QSB400 |
| Load Regulation | ±0.5% |
| Maximum Temperature | +100°C |
| Minimum Temperature | -40°C |
| Standards Met | EN 55022, MIL-HDBK-217F |
