คุณสมบัติ | รายละเอียด |
---|---|
Maximum Load Current | 25 A |
Mounting Type | Panel Mount |
Maximum Load Voltage | 530 V ac |
Minimum Load Voltage | 48 V ac |
Minimum Control Voltage | 4 V dc |
Maximum Control Voltage | 32 V dc |
Switching Type | Zero Cross |
Control Voltage Range | 4 → 32 V dc |
Terminal Type | Screw |
Output Device | SCR, TRIAC |
Relay Type | Single Phase |
Series | KSI |
Maximum Turn On Time | 10ms |
Load Voltage Range | 48 → 530V ac |
Dimensions | 58.4 x 45.7 x 20.5mm |
Off State Leakage Current | 5 mA |
Minimum Operating Temperature | -30°C |
Operating Temperature Range | -30 → +80°C |
Length | 58.4mm |
Height | 20.5mm |
Maximum Operating Temperature | +80°C |
Standards Met | CCCs, CE, CULus, TUV |
Depth | 45.7mm |
Special Features | Build-In MOV/TVS Option, DC Control, Dielectric Strength, LED Indicator, TRIAC or SCR Output |
