รายละเอียดสินค้า / Product Details
คุณสมบัติ | Value |
---|---|
Detection Range | Maximum of 800 mm |
Output Type | Analogue, PNP |
Body Style | Barrel |
Thread Size | M18 x 1 |
Transducer Frequency | 230kHz |
Maximum DC Voltage | 30V |
Supply Voltage | 10 → 30 V dc |
Terminal Type | 4-Pin M12 Connector |
IP Rating | IP67 |
Housing Material | Epoxy Glass Ceramic, Polyamide, Stainless Steel |
Reverse Polarity Protection | Yes |
Short Circuit Overload Protection | Yes |
Switching Current | 35 mA |
Response Time | 0.1 s |
Length | 60.5mm |
Standards Met | CE, CULus, CULus Recognised, EN 55011, EN 60068-2-27, EN 60068-2-6, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, UL |
Maximum Operating Temperature | +70°C |
Sensor Configuration | Diffuse Reflection |
Minimum Operating Temperature | -20°C |
